4
TOTALHARMONIC
DISTORTION
Coaxial 1 20 Hz
With a 0 dBFS, 1 KHz sinewave PCM
bitstream, andMain Volumeat 20 dB below
Max, set meter to read THD+N , with % units.
Use10Hz-80KHz BW. ReadTHD+NRatio,
with dBr units on both FL and FR Speaker
Outputs. IHF-AFILTER
% <0.25 <0.15
1KHz
With a 0 dBFS, 20 Hz sinewave PCM
bitstream, andMain Volumeat 20 dB below
Max, set meter to read THD+N , with % units.
Use10Hz-80KHz BW. ReadTHD+NRatio,
with dBr units on both FL and FR Speaker
Outputs.IHF-AFILTER
% <0.6 <0.4
20 KHz
With a 0 dBFS, 20 KHz sinewavePCM
bitstream, andMain Volumeat 20 dB below
Max, set meter to read THD+N Ratio, with %
units. Use 10 Hz-80 KHz BW. Read THD+N
Ratio, onboth FL and FR Speaker Outputs.
% <0.25 <0.15
5
IMD(SMPTE)
Coaxial 1
Sine wave # 1 f
=80Hz.Ampl=4,
sine wave # 2 f= 2
KHz. Ampl=1
With a 0 dBFS, SMPTE (80 Hz-4X:2 KHz-1X)
waveformPCM bitstream, and MainVolume
at
20 dB belowMax, set meter to read
SMPTE/DIN Distortion, with % units. Read
SMPTE/DIN Distortion, on both FL and FR
Speaker Outputs.
%0.60.4
6
S/N RATIO,IHF-A FILTER
Coaxial 1
With a 0 dBFS, 1 KHz sinewave PCM bitstream,and Main Volume
at 20 dB below Max, record the Output Voltage at FL and FR
speaker outputs to be the 0 dBr Reference value. Set Digital
Generator amplitude to -999 dBFS (Generator turned off),Then
set
meter t
dB >85 > 90
Coaxial 1
With a 0 dBFS, 1 KHz sinewave PCM bitstream,and Main Volume
adjusted to obtain 1 W output into an 8 ohm load. Record the
Out
Voltage at FL and FR speaker outputs to be the 0 dBr Reference
value. Set Digital Generator amplitude to -999 dBFS (Generator
dB > 70 >75
7
CHANNEL SEPARATION:
Zterm= 1KW/1000pF
Coaxial1 100Hz
With a 0 dBFS, 100 Hz sinewave PCM
bitstream, andMain Volumeat 20 dB below
Max, set meter to read Crosstalk, with dB
units. Use 10 Hz-80 KHz BW. Read Crosstalk,
when driving FL only, and measuring FR. Then,
read Crosstalk, when driving FR only, and me
dB >60 >65
1KHz
With a 0 dBFS, 1 KHz sinewave PCM
bitstream, andMain Volumeat 20 dB below
Max, set meter to read Crosstalk, with dB
units. Use 10 Hz-80 KHz BW. Read Crosstalk,
when driving FL only, and measuring FR. Then,
read Crosstalk, when driving FR only, and mea
dB >60 > 65
10 KHz
With a 0 dBFS, 10 KHz sinewavePCM
bitstream, andMain Volumeat 20 dB below
Max, set meter to read Crosstalk, with dB
units. Use 10 Hz-80 KHz BW. Read Crosstalk,
when driving FL only, and measuring FR. Then,
read Crosstalk, when driving FR only, and me
dB >50 >60
9
put
DETAILED SPECIFICATIONS (CONT'D)
DPR1001 harman/kardon
