PAGE
Switching Mode Power Supply
2002/11/5
APPROVAL
DATE
REVISION
0
R&D
K J P –3011
MODEL
KIJIN
KIJIN ELECTRONIC CO.,LTD
4-3. ABNORMAL CONDITION AND REQUIRED RESPONSE
4-3-1. Output Short Circuit Protection
4-3-1-1. On the output, Application of a short-circuit to ground shall not
be damaged to the power supply.
4-3-1-2. When short problem is occurred, Hiccup or Fold back
After removing of short, the power supply will be auto-recovered
4-3-2. Min Load Operation.
4-3-2-1. The power supply shall not be damaged by on load operation.
4-3-2-2. The power supply does not required to maintain output voltage
within requlation limit.
4-3-3. Overload Protection
4-3-3-1. Input : AC 120V
Output : 120% Minimum
4-4. Safety Agency and Regulatory
4-4-1. Safety Agency
4-4-1-1. Safety :UL.CSA.Meete
4-4-2 HI-POT and Insulation Resistance
4-4-2-1. Dielectric Withstanding Voltage
Primary to Secondary : 2.5K Vac, 1Minite.
For production test procedure, the duration is 1 sec.
31
SMPS
DPR1001 harman/kardon
