MODEL NO: KJP-3011
PAGE
Switching Mode Power Supply
2002/11/5
APPROVAL
DATE
REVISION
0
R&D
K J P –3011
MODEL
KIJIN
KIJIN ELECTRONIC CO.,LTD
4-4-2-2. Hi-pot test is performed with minimum 10mA cut-off current.
4-4-2-3. Insulation resistance : MIN 100M
Ω
(Primary to Secondary)
4-4-3. EMI
4-3-3-1. FCC class B. Meete
4-5. Environmental Requirements
4-5-1. Operating Temperature : 0 to 40
℃
4-5-2. Storage Temperature : -40 to 85
℃
4-5-3. Operating Humidity : 20 to 80% RH
4-5-4. Storage Humidity : 10 to 90% RH
4-5-5 ALTITUDE
Operating : 10,000 ft
Storage : 50,000ft
5. MEAN TIME BETWEEN FAILURES(MTBF)
50,000 hours (full load and 25 ℃ ambient conditions)
6. BURN-IN
TEST CONDITION
4 hours referance (@70% Load min., 40℃, 120Vrms)
32
SMPS
DPR1001 harman/kardon
