63
NO Command Syntax Example
24
VIDOUT_TESTPAT
VIDEO_TESTPATTERN
Command:
SEND_COMMAND <DEV>,
“‘VIDOUT_TESTPAT-<pattern>'"
Return:
VIDOUT_TESTPAT-<pattern>
Description:
Sets the test pattern for the video
output port.
Variables:
<pattern>={BLACK|BLUE|WHITE|RE
D|GREEN|OFF}
Command:
SEND_COMMAND
VIDEO_OUTPUT_1,
“'VIDOUT_TESTPAT-RED'"
Return:
VIDOUT_TESTPAT-RED
Description:
Sets the test pattern to RED
for the video output port #1.
25
?VIDOUT_TESTPAT
?VIDEO_TESTPATTERN
Command:
SEND_COMMAND <DEV>,
“‘?VIDOUT_TESTPAT'"
Return:
VIDOUT_TESTPAT-<pattern>
Description:
Requests the test pattern setting for
the video output port.
Command:
SEND_COMMAND
VIDEO_OUTPUT_1,
“'?VIDOUT_TESTPAT'"
Return:
VIDOUT_TESTPAT-BLACK
Description:
The test pattern of the video
output port #1 is BLACK.
26 VIDOUT_ON
Command:
SEND_COMMAND <DEV>,
“‘VIDOUT_ON-<ENABLE|DISABLE
>'"
Return:
VIDOUT_ON-<ENABLE|DISABLE>
Description:
Enable or disable a video output.
Command:
SEND_COMMAND
VIDEO_OUTPUT_1,
“'VIDOUT_ON-ENABLE'"
Return:
VIDOUT_ON-ENABLE
Description:
Enable video output #1.
27 ?VIDOUT_ON
Command:
SEND_COMMAND <DEV>,
"'?VIDOUT_ON'"
Return:
VIDOUT_ON-<ENABLE|DISABLE>
Description:
Requests to see if a video output is
enabled or disabled.
Command:
SEND_COMMAND
VIDEO_OUTPUT_1,
“'?VIDOUT_ON'"
Return:
VIDOUT_ON-DISABLE
Description:
Video output #1 is disabled
