72618 P/N: 630-00100 Rev E
SL300 • Pinnacle Stair Lift Installation Manual
15
Pinnacle SL300COMPLETION PROCEDURES
7. Repeat the above tests while driving the lift in
opposite direction.
8. If any safety condition does not function properly,
carefully review all installation instructions, reset the
“ON /OFF” switch. Repeat the above tests.
9. If any safety stop switch fails to immediately
stop the lift, immediately call the manufacturer for
assistance in diagnosing and repairing the problem.
DO NOT USE THE LIFT.
E. ADDITIONAL SYSTEM CHECKS
1. After the successful testing of all safety switches,
sit on the lift and operate to the top of the stairs.
Keeping the control switch depressed continuously,
the lift should gently decelerate and then stop at
the top of the rail.
2. As a nal adjustment, sit on the lift and do two
(2) complete up trips and stop with the chair at
the bottom. Then tighten the compression screw
in the top end plate, then run the chair to the top
and again tighten the compression screw. Run the
chair to the middle and do a nal tightening of the
compression screw.
3. Drive the lift to the bottom, keeping the control
switch depressed all the time, and check that the lift
gently decelerates and stops so the footrest pan is
clear of the oor. If necessary adjust the limit cams
with a 5/64" Allen wrench.
4. Move the lift about 3 ft from either the top
or bottom of the rail. After 30 seconds the beep
indicating that the lift is not positioned on a charge
point. The beep will stop after 30 seconds .
5. Test the seat swivel at the top by using the levers
and swiveling the seat towards the landing and
stop the seat at 35 and 85 degrees. The seat swivel
levers will release into a locked position at each of
these angles. The lift will not operate in any of these
positions if the control switch is depressed. Return
the seat to its normal position and the lift will now
operate normally.
