20
Pinnacle SL300
FOLDING RAIL INSTALLATION
TECHNICAL SPECIFICATIONS
CM
Technical Specicaons
Weight Capacity 300 lb
Track (Rail) Type Aluminum Extrusion
Travel
15'6" standard - 32' max
Avg. # of Return Trips per Charge 40
Minimum Folded Width
11.0" / 13.0" Folding Rail
Minimum Footrest Height
2.5"
Clear Distance Between Armrests
20"
Floor to Seat Height
20"
Minimum Wall to Side of Rail
6"
Seat Base
15" Deep, 18" Wide
Seatback
9.5" Tall, 16" Wide
Footrest Size
12.5" Wide, 15" Long
Electrical Requirements 120 / 240 VAC
Batteries 2 12v; 7.2amp hr.
Drive System Nylon Polymer Worn Gear
Safety Standards Complies with ASME A18.1 & ASME A17.5
Warranty 2 Year Parts / 10 Year Gear Rack / 1 Year Batteries
