2
Pinnacle SL300 CONTENTS
Read and understand this manual prior to
attempting stair lift installations. Please refer
to the Owner’s Manual for Limited Warranty
information and operating instructions. The Owner’s
Manual must be reviewed with and given to the owner
of the lift before it is put into service.
Any alterations to the equipment without written
authorization by the manufacturer may void
the warranty.
Harmar lifts are designed to be installed with as
little assembly by the installer as possible. If you
have questions, concerns or comments related to
installation, please contact Harmar’s Technical Service
Department.
Contents
PRELIMINARY CHECKS 3
Tools Required ...............................3
Included Parts ................................3
INSTALLATION PROCEDURES 4-12
Determine Rail Length ........................4
Rail Installation .............................5-6
Chassis Installation ............................7
Final Rail Installation ........................8-9
Footrest and Seat Installation ..............10-11
Procedure to Switch Armrest Control .........11
Audible Tones ................................12
Major Fault Tones ............................12
REMOTE CONTROL OPERATION 13
Remote Control Operation ...................13
Remote Control Reprogramming .............13
COMPLETION PROCEDURES 14-15
Test Armrest Control Switch ..................14
Tighten Brackets .............................14
Set Upper and Lower Travel Limits ............14
Test Safety Stop Switches ..................14-15
Additional System Checks ....................15
FOLDING RAIL INSTALLATION 16-19
TECHNICAL SPECIFICATIONS 20
END-USER FAMILIARIZATION 21
NOTES 22-23
SYMBOLS USED IN THIS MANUAL
READ MANUAL - Pay close attention to
the instructions in the manual.
CAUTION - Hazardous situation. If not
avoided, could result in serious damage
to property.
WARNING - Hazardous situation. If not
avoided, could result in serious injury to
installer or user.
TIP - Helpful tips that will facilitate ease
of installation.
INDICATIONS OF USE STATEMENT
The Pinnacle SL300 Series is to assist transfer of
patients or mobility impaired persons, up and down
between levels of a residential home.
