SL600 PINNACLE STAIRLIFT: Owner’s Manual
22MAR24 | 76016 E
13
OPERATION
PINNACLE STAIRLIFT: SECTION 3
POWER FOLDING
FOOTREST (OPTIONAL)
For units featuring the optional Power Footrest,
a footrest control switch is conveniently located
beneath the right armrest (or left if repositioned by
the installer).
RAISE OR LOWER THE FOOTREST
1. Press and hold the rocker switch.
2. Continue to hold the rocker switch until the
footrest stops moving.
See Figure 3-11.
Up
Down
Figure 3-11
Always hold the rocker switch unl the footrest
stops moving on its own. If you release the switch
early, re-engage it, so the footrest is fully raised or
lowered. DO NOT move the footrest manually or by
stepping on it. This may lead to damage and void
the warranty. If your footrest will not deploy fully,
contact your dealer for assistance.
CAUTION
!
NOTE: Ensure that the footrest is not blocked by an object.
If the power footrest hits an obstruction a self-resetting
fuse will be triggered. The power footrest will require 30
seconds to reset.
FOLDING RAIL
AUTOMATIC ACTIVATION
• The chassis will automatically activate the
folding rail as you ascend or descend the stairs.
• This activation occurs when the stairlift is in
motion and nearing the hinge point.
• Ensure that there are no people, pets, or
obstructions around the lower landing during
this process.
• To stop, release the hand control, and the
folding rail will cease operation automatically.
BETWEEN USES
• To maintain a clear landing area, utilize the
remote call/send function to move the stairlift
up into the stairwell.
• Continue until the folding rail leg in a vertical
position.
• The lift will enter a charging mode in this
position.
See Figure 3-12.
Figure 3-12
To Next Page
