SL600 PINNACLE STAIRLIFT: Owner’s Manual
22MAR24 | 76016 E
6
INTRODUCTION
PINNACLE STAIRLIFT: SECTION 2
KEY STAIRLIFT FEATURES
1. LED indicator light
2. Armrests
3. Top safety obstruction sensor
4. Footrest with obstruction sensors
5. Up/Down Control
6. Seatbelt
7. Seat swivel release bars
(not used on power swivel)
8. Bottom safety obstruction sensor
9. Power footrest switch (optional)
SAFETY FEATURES
• There are spring loaded sensors on the top and bottom of the carriage, and the front, back and underside
of the footrest. If any of these edges touches an obstruction, the lift will halt immediately and the armrest
LED indicator light will turn orange. The lift may only be driven away from the obstruction.
• An interlock on the swivel seat prevents the lift from being operated unless the seat is in its normal,
locked position.
• The remote controls are disabled for 15-seconds after the armrest control is used.
• A retractable seat belt is provided and must be secured around the user to prevent an inadvertent fall.
1
2
3
4
5
6
7
8
9
