SL600 PINNACLE STAIRLIFT: Owner’s Manual
22MAR24 | 76016 E
8
OPERATION
PINNACLE STAIRLIFT: SECTION 3
SECTION 3
OPERATION
STAIRLIFT
POWER ON: To turn the stairlift on, press the red
“On/Off” switch located on the top of the chassis to
the “On” position. Ensure that the optional key
switch is also set to “ON”. The presence of the green
light on the armrest, along with the audible beep,
serves as conclusive confirmation that the lift is
primed for operation.
See Figure 3-1.
On/Off
switch
Figure 3-1
Do not carry pets or children on your lap while riding
the stairli. The li is designed for use by only one
person at a me.
CAUTION
!
ENTRY ASSISTANCE: Raise the armrest on the entry
side to facilitate entry into the chair. When
positioning yourself in the seat at the upper landing,
ensure the seat is fully swiveled away from the
staircase and securely locked for safety. Lower the
footrest to assist with entry and maintain proper
foot positioning during transport.
See Figure 3-2.
Figure 3-2
SEATING PREPARATION: Before operating the lift,
ensure you are securely seated with the armrests in
the down position. Identify the seatbelt, typically
positioned across the seat. Ensure the seatbelt is
free of any twists or knots. Insert the metal buckle
in the corresponding receptacle until you hear a
click. Adjust the length of the seatbelt to achieve a
snug and comfortable fit. Confirm that the seatbelt
is securely fastened by giving it a gentle tug.
See Figure 3-3.
Figure 3-3
Always be careful when sing down. Use the
armrests to gently guide yourself into the seat. DO
NOT “drop” yourself into the seat.
CAUTION
!
Never aempt to operate the li while standing up.
Always sit in the center of the seat with the seatbelt
fastened around your waist. Do not lean to the side
while the li is in moon.
CAUTION
!
