SL600 PINNACLE STAIRLIFT: Owner’s Manual
22MAR24 | 76016 E
18
TROUBLESHOOTING
PINNACLE STAIRLIFT: SECTION 5
MINOR FAULTS
Single long beep. Will reset once fault is cleared.
• Seat swiveled out of position
• Edge safety detected
• Footrest
• Current overload condition
• A low battery voltage condition
POWER SWIVEL FAULTS
Problem: Lift stops while not at a landing. DO NOT
STAND UP. The power swivel is equipped with a
recovery mode in the event the seat comes out of
the home position.
Solution: Release the controls. Press the down
button on the Up/Down Control in the armrest. The
seat will rotate back into the home position and the
lift will start to move in the down direction.
Problem: The seat starts and stops during rotation.
Solution: The electronics are protected by a self-
resetting fuse that will trigger if the seat is run
against a stop for more than 5-seconds. If triggered
the fuse needs to rest for 2-minutes to ensure
proper operation.
POWER FOOTREST FAULTS
Problem: Footrest will not operate.
Solution: Confirm that the footrest control cable
(4-pin) is plugged into the chassis. Contact your
dealer for assistance. DO NOT use the lift if the
footrest is not fully lowering.
MANUAL OVERRIDE
OPERATION
In the event of a lift failure where the operator is
unable to exit the lift on the stairway, the optional
manual override tool can be employed to lower or
raise the lift to a landing. Follow these steps for
manual operation:
1. Confirm that the operator cannot exit the lift on
the stairway and follow the instructions on the
bottom safety flap of the lift.
2. Turn the lift’s On/Off switch to the “Off”
position.
3. Insert the manual override tool into the hole in
the lower safety flap until it engages the motor
shaft.
4. Turn the manual override tool in the desired
direction (either to lower or raise the lift) as per
your requirements.
Following these guidelines ensures a safe and
effective manual override operation in case of lift
malfunction. Always prioritize safety and adhere to
the provided instructions for a secure manual
operation experience.
Do not operate the li with the manual override
tool engaged.
WARNING
!
