Harmar Mobility Pinnacle SL600 - Lift Operation and Storage

SL600 PINNACLE STAIRLIFT: Owner’s Manual
22MAR24 | 76016 E
9
OPERATION
PINNACLE STAIRLIFT: SECTION 3
LIFT OPERATION: To operate the lift, continuously
press the hand control on the armrest in the desired
travel direction. Release the hand control switch to
stop the lift. Press the hand control until you reach
the intended landing. The lift will gently stop at the
preset point.
See Figure 3-4.
Up/Down
control
switch
Figure 3-4
Keep your feet centered on the footrest while
traveling up and down the stairs. Never dangle your
feet o the footrest while riding the li.
CAUTION
!
NOTE: An amber light and a single beep indicates that
the lift has touched an obstruction. Clear the obstruction
before proceeding.
If the lift is parked at the charge station and it is beeping
intermittently, it could be because the power supply is not
connected to the AC power. See Figure 3-5.
LED light
Figure 3-5
UPPER LANDING: At the upper landing, swivel the
seat away from the staircase until the seat is fully
swiveled and locked. Remove the seat belt before
standing.
See Figure 3-6.
Figure 3-6
SAFE EXIT: Position yourself so that your feet are
not directly over the footrest. Utilize the armrests
for support as you prepare to exit. Gradually rise
off the seat while maintaining a firm grip on the
armrests.
FOLD FOR CONVENIENCE: If you do not intend to
use the lift for a while, fold up the seat, footrest,
and armrests to minimize obstruction of the stairs.
See Figure 3-7.
Figure 3-7
Be careful while walking close to the li. Take care
not to trip over a lowered footrest.
CAUTION
!
