SL600 PINNACLE STAIR LIFT: Install Manual
30SEP2020 | 76015 REV F
17
INSTALLATION
PINNACLE STAIR LIFT: SECTION 4
5. Measure to verify that the underside of the
at the second step bracket and at the upper
bracket. If not, reposition the brackets as
needed. This clearance is required for the
stair lift footrest. In some installations, you
standard stair-bracket. Contact Harmar to get
tall brackets.
See Figures 4-40 and 4-41.
Figure 4-40
Figure 4-41
6. Measure from the side of the rail to the wall.
The minimum clearance that will work with a
from the wall or more. This will leave about
See Figure 4-42.
Figure 4-42
7. Fasten down the near corner of the lower
bracket using a drill that has extensions at
See Figures 4-43 and 4-44.
Figure 4-43
Figure 4-44
8. Measure from the side of the rail at the upper
bracket of the folding rail.
of the bracket.
9. Connect to upper rail, following regular
procedures (see page 5). This procedure
includes plugging the battery charging wire
harness for the folding rail into the charging
harness from the upper rail. The power supply
itself can be plugged into either the top rail
(for the top of the stairs), or to the charge
plug from the folding rail, which comes out
just higher than the folding mechanism for the
bottom of the stairway.
10. Fasten the other screws of both rail brackets
using the power drill and long extension with
See Figure 4-45.
