Chapter 1: ProStream X hardware specifications and reference topics
ProStream X control panel
A diagram of the ProStream X control panel.
Key Component
1. For future use
2. For future use
3. NIC 1 Activity LED
4. For future use
5. System status LED
6. Power button with integrated LED
7. Hard drive activity LED
8. NIC 2 activity LED
ProStream X rear panel
A diagram of the ProStream X rear panel components.
Key Component Description
1. AC Power connector
2. Release Lever Secures power supply module to the chassis.
3. Power supply LED Dual redundant power supplies. LED functions detailed below.
