SPECIFICATIONS
MEASURES AND WEIGHTS
Height of cut (standard) mm 0-110
Height of cut (max.)
mm
135
Width of cut mm 625 of 1250
Diam. saw-blade (standard) mm
∅
400
Diam. saw-blade (max.) mm
∅ 450
Saw-blade bore mm
∅
30
Angle adjustment 0-45°
Distance saw-blade centre to
front table
mm 580
Table size
mm
965*1125
Table height
mm
850
Motor power kW 5.5
hp
7.5
Voltage V 380
Spindle speed
rpm
2800
Weight
kg
320
Used saw-blades have to be conform to prEN 847-1.
Maximum thickness of saw-blade 3.6 mm.
NOISE INFORMATION
Used saw-blade: :Leuco proline 101420/10005 ∅400
Z=48 d=30.
A-weighed Equivalent Continuous Noise Pressure
Idle dB(A) :81.0 dB(A)
Loaded dB(A) :84.4 dB(A)
Measuring performed according to DIN 45635 part 1659. Measured when cutting chipboard thickness
18 mm, length 2 meters.
Safe deviation can be approx. 3 db(A).
The above-mentioned values are radiated noise pressures and not necessarily noise pressures to
work safely with this machine. Supplementary measures for ear protection can be necessary. The
following can be of influence:
 duration of operations
 working area
 other noises
Maximum value may vary per country. Above information can be used for better valuation of dangers
and risks subsequent to using this machine.
