TECHNICAL DETAILS
MEASURES AND WEIGHTS
Technical data:
625-H 625-U 625-2K
Height of cut (standard) mm 135 135 135
Height of cut (max.) mm 160 160 160
Height of cut angle 45º mm - 70 -
Length of cut mm 625 625 1250
Length of cut angle 45º mm - 625 -
Length of cut arm at 45º mm - 400 -
Height adjustment mm 95 50 95
Saw-blade diameter standard mm Ø 400 Ø 400 Ø 400
Saw-blade diameter max. mm Ø 450 Ø 450 Ø 450
Saw-blade bore mm Ø 30 Ø 30 Ø 30
Adjustable arm mm - 0-45º -
Measures table top mm 800*940 800*1470 1645*940
Table height mm 840 840 840
Motor power kW 3 3 3
Voltage V 400V 3~ 400V 3~ 400V 3~
Spindle speed rpm 2800 2800 2800
Weight kgs 211 218 348
Used saw-blades must be conform prEN 847-1.
Maximum thickness of saw-blade is 3.6 mm.
NOISE INFORMATION
Used saw-blade: :Leuco proline 101420/10005 ∅400, Z=48 d=30.
A-weighed Equivalent Continuous noise Pressure
Idle dB(A) :81.0 dB(A)
Loaded dB(A) :84.4 dB(A)
Measuring performed according to DIN 45635 part 1659. Measured when cutting chipboard, thickness
18 mm, length 2 meters.
Safe deviation can be approx. 3 dB(A).
The above-mentioned values are radiated noise pressures and not necessarily noise pressures to work
safely with this machine. Supplementary measures for ear protection can be necessary. The following
can be of influence.
 duration of operations
 working area
 other noises
Maximum value may vary per country. Above information can be used for better valuation of dangers
and risks subsequent to using this machine.
