II. Confirm Chiller Model and Number of Frame Sections
Frame Sections
Details: The Haskris OPC series chillers are built with a system of parallel refrigeration circuits and
associated frame sections to house those components. Larger models of chiller have more
refrigeration circuits and more frame sections.
Instructions: Use the chiller model and the table below to determine the number of refrigeration
circuits and sheet metal sets are used in the design.
Haskris Chiller Model
Refrigeration Circuits
Frame Sections*
OPC3 through OPC15
1
1
OPC16 through OPC26
2
2
OPC30
2
3
OPC36
3
3 or 4
OPC48
4
4 or 5
OPC60
5
5 or 6
*Some units are designed with customizations that may change the number of frame sections
Refrigeration Circuits and Frame Sections by Model
