IV. Installation: Electrical, Connection to Outdoor Chiller
Electrical
• Comply with proper local electrical codes.
• Contact a licensed electrician to perform the electrical installation.
• The electrician should verify that the wiring is adequate in the installation area.
• Refer to the heat exchanger specification document or the unit’s nameplate label for detailed
electrical requirements.
• Do not mount or support any electrical service disconnect directly to the heat exchanger.
Electrical connection: Use a dedicated service disconnect and time delay fusing. Connect incoming
electrical to the distribution block in the electrical box.
Distribution Block
