Hasselblad H2 User Manual

86
Bracketing using predetermined number of exposures (2, 3 or 5) in 1/3, 1/2, or 1 EV step difference
intervals.
Number of frames from 2 to 255 and interval from 1 second to 24 hours.
Film speed range ISO 6 to 6400. Automatic setting with Barcode film.
The camera features two dot-matrix LCD’s that provide clear and easy-to-understand information to the
user. One is located on the grip and the other in the 90° viewfinder. The magazine has a segment based
LCD.
Bright Spherical Acute-Matte type D. Optional type with grid markings also available.
Provided with two M5 threads and an electrical connector for accessories.
A large number of the H2’s functions can be customized by the photographer to suit specific styles or
situations through the built-in menu system.
Both basic and advanced functions are set using buttons and control wheels on the camera body in
conjunction with the graphic interfaces.
A cassette for 3 CR-123 Lithium type batteries. Optional cassette with fixed rechargeable batteries.
Li-ion type. 7.2 V / 1850 mAh output.
Uses DV charge termination technique to prevent over-charging.100–240 VAC / 50–60 Hz input.
6.0–7.9 VDC/ 800mA output
All external dimensions are approximate and include fitted protective caps and covers.
H2 Camera body: 89 x 155 x 117 mm (L,W,H): 3.5 x 6.1 x 4.6 ins.
HV 90X Viewfinder: 140 x 78.5 x 52 x mm (L,W,H): 5.5 x 3.1 x 2.0 ins.
HM 16-32 Film magazine: 64 x 98 x 84 mm (L,W,H): 2.5 x 3.9 x 3.3 ins.
HC 2.8/80mm lens: 85 x 84 mm (L,W)
(width 89 mm with lens shade mounted in reverse): 3.3 x 3.3 ins.
All weights are approximate and include fitted protective caps and covers, batteries and film.
H2 Camera body: 820 g – 28.9 oz.
HM 16-32 film magazine: 475 g – 16.7 oz.
HV 90X Viewfinder: 325 g – 11.5 oz.
HC 2.8/80mm lens: 500 g – 17.7 oz.
Auto bracketing
Interval timer
Film speed
Displays
Focusing screen
Accessory connection
Customization
User interface
Power supply
Battery grip rechargeable 7.2 V
Battery charger Li-ion 7.2 VDC
External dimensions
Weight

Hasselblad H2 Specifications

General

Camera Type	Medium Format DSLR
Sensor Type	CCD
Sensor Size	36.7 x 49.0 mm
Lens Mount	Hasselblad H
Shutter	Focal Plane Shutter
Flash Sync Speed	1/800 sec
ISO Range	50-400
Shutter Speed Range	32 min to 1/800 sec
Focus Modes	Manual, Autofocus
Exposure Modes	Program, Aperture Priority, Shutter Priority, Manual
Storage	CF card
Weight	1460 g (without lens)
