Hasselblad H2 User Manual

37
Magazine settings
Press the function selector (
button ) repeatedly to successively
access:
A. Film speed (ISO / Bar Code)
B. Film length (120/220/ Number of frames)
C. Data (on/off)
D. Frame counter (count down / count up)
E. Low-battery warning symbol
Film speed setting / Barcode
e film speed (ISO / ASA) can be set automatically or manu-
ally. Automatic setting uses a Barcode (only some films have this
feature). is is the default setting.
 Film settings (ISO / film length) are automatic only if the magazine
is set at Barcode automatic. That is, a barcoded film cannot override
a manual film speed setting but a manual setting can override the
film speed of a barcoded film.
 Films without a barcode must have their speed set manually. A
manual setting must also be made if you want to override the
speed setting of a barcoded film.
To access Manual setting:
1) Ensure the magazine settings lock is in the unlocked position.
2) Press the
button until a figure (or barcode symbol) appears
together with ISO.
3) Press either the
or the
button to reach the required set-
ting.
4) The new setting will be saved automatically after a time out of
five seconds.
5) Return the LCD settings lock to the locked position.
 If you use both standard and barcoded films (or overridden barcoded
films), check that you have changed the settings accordingly.
Film length/number of frames
Both 120 and 220 films can be used. 120 film will produce 8 (for
use with ‘half-length’ 120 films only) or 16 frames and 220 film
will produce 32 frames.
If the film has a barcode, then film length setting (and film speed
setting) is automatic. e LCD will automatically show the barcode
symbol and the appropriate film length. (Note that film speed can
be overridden with barcoded films, but not film length).
If, however, the film has no barcode then proceed as follows:
To access film type setting:
1) Ensure the magazine settings lock is in the unlocked position.
2) Press the
button until the 120 or 220 symbol appears.
3) Press either the
or the
button to change the desired
setting.
4) The new setting will be saved automatically after timeout.
5) Return the magazine settings lock to the locked position.
A
B
C
D
E
Film speed
Film length
Data
Frame counter
1 2
3
4
4
5
EXAMPLE
