Hatco 3CS-3 - Dimensions

10
Form No. 3CSFRM-0118
English
Model
Width
(A)
Depth
(B)
Height
(C)
FRC-I
12-3/4″
(325 mm)
20-7/8″
(530 mm)
19-7/8″
(503 mm)
FRC-II
15-5/8″
(397 mm)
23-3/4″
(603 mm)
34-1/4″
(870 mm)
Model A B C D E F
3CS-X
and FR-X
16-7/8″
(429 mm)
5-1/2″
(140 mm)
8-1/2″
(216 mm)
2-7/8″
(73 mm)
6-3/4″
(171 mm)
3-3/8″
(86 mm)
3CS-XB and
FR-XB
17-1/8″
(435 mm)
4-5/8″
(117 mm)
8-1/2″
(216 mm)
4″
(102 mm)
8″
(203 mm)
4″
(102 mm)
SPECIFICATIONS
Dimensions
A
B
C
D
E
2-7/8″
(73 mm)
9-3/4″
(248 mm)
12-5/8″
(321 mm)
1″
(25 mm)
Side View
Rear View
F
2″ (51 mm)
1-1/2″
(38 mm)
Dimensions—3CS and FR Models
Dimensions—FRC Models
C
A
B
C
A
B
FRC-II
FRC-I
Dimensions—FRC Models
