Model Voltage
Kilowatts
(kW) Phase Amps
Wiring Sizing
AWG*†
Fuse or
Circuit
Breaker*
Shipping
Weight
FR-3B 208 3.0 3 (Bal.) 8.3 14 15 30 lbs. (14 kg)
240 3.0 3 (Bal.) 7.2 14 15 30 lbs. (14 kg)
480 3.0 3 (Bal.) 3.6 14 15 30 lbs. (14 kg)
380–400–415 2.8–3.1–3.4 3 (Bal.) 4.3–4.5–4.7 14 15 30 lbs. (14 kg)
FR-4B 208 4.5 3 (Bal.) 12.5 12 20 30 lbs. (14 kg)
240 4.5 3 (Bal.) 10.8 14 15 30 lbs. (14 kg)
480 4.5 3 (Bal.) 5.4 14 15 30 lbs. (14 kg)
380–400–415 3.8–4.1–4.5 3 (Bal.) 5.7–6–6.2 14 15 30 lbs. (14 kg)
FR-6B 208 6.8 3 (Bal.) 18.8 10 30 30 lbs. (14 kg)
240 6.0 3 (Bal.) 14.4 12 20 30 lbs. (14 kg)
380 6.0 3 (Bal.) 10.2 14 15 30 lbs. (14 kg)
380–400–415 5.6–6.3–6.7 3 (Bal.) 8.6–9–9.4 14 15 30 lbs. (14 kg)
480 6.0 3 (Bal.) 7.2 14 15 30 lbs. (14 kg)
FR-9B 208 9.0 3 (Bal.) 25 10 40 30 lbs. (14 kg)
240 9.0 3 (Bal.) 21.7 10 30 30 lbs. (14 kg)
380 9.0 3 (Bal.) 12.9 12 20 30 lbs. (14 kg)
440 9.0 3 (Bal.) 11.8 14 15 30 lbs. (14 kg)
480 9.0 3 (Bal.) 10.8 14 15 30 lbs. (14 kg)
380–400–415 7.6–8.3–9.0 3 (Bal.) 11.5–11.9–12.5 12 20 30 lbs. (14 kg)
Model Voltage
Kilowatts
(kW) Phase Amps
Wiring Sizing
AWG*†
Fuse or
Circuit Breaker* Shipping Weight
FRC-I 208 3.0 1 14.4 12 20 42 lbs. (19 kg)
220–230 2.5–2.8 1 11.5–12 14 15 42 lbs. (19 kg)
240 3.0 1 12.5 12 20 42 lbs. (19 kg)
FRC-II 208 3.0 1 14.4 12 20 69 lbs. (31 kg)
220–230 2.5–2.8 1 11.5–12 14 15 69 lbs. (31 kg)
240 3.0 1 12.5 12 20 69 lbs. (31 kg)
SPECIFICATIONS
The shaded areas contain electrical information for International models only.
* Wire size is based on THHN wire for branch circuit protection at 0.91 derate factor. Circuit breakers and fused
disconnects are to be mounted remote and wired by contractor. Sizes are based on the 2002 NEC table 310-16. Conduit
size based on conductors plus ground wire sizing per Table C1 from Appendix C.
† Based upon THHN wire rated 90ºC.
♦ Open Delta–standard construction (Amperage higher than Balanced 3-phase)
NOTE: Shipping Weight includes packaging.
Electrical Rating Chart—FR-XB Models
Electrical Rating Chart—FRC Models
