Hatco 3CS-3 User Manual

8
Form No. 3CSFRM-0118
English
Model Voltage
Kilowatts
(kW) Phase Amps
Wiring Sizing
AWG*†
Fuse or
Circuit Breaker*
Shipping
Weight
FR-3 208 3.0 1 14.4 12 20 24 lbs. (11 kg)
240 3.0 1 12.5 12 20 24 lbs. (11 kg)
480 3.0 1 6.3 14 15 24 lbs. (11 kg)
220–230–240 2.5–2.8–3.0 1 11.5–12–12.5 12 20 24 lbs. (11 kg)
380–400–415 2.8–3.1–3.4 1 7.4–7.8–8.1 14 15 24 lbs. (11 kg)
208 3.0 3♦ 8.3 14 15 24 lbs. (11 kg)
240 3.0 3♦ 7.2 14 15 24 lbs. (11 kg)
380–400–415 2.8–3.1–3.4 3♦ 4.3–4.5–4.7 14 26 24 lbs. (11 kg)
FR-4 208 4.5 1 21.6 10 30 24 lbs. (11 kg)
240 4.5 1 18.8 10 30 24 lbs. (11 kg)
480 4.5 1 9.4 14 15 24 lbs. (11 kg)
220–230–240 3.8–4.1–4.5 1 17.2–18–18.8 10 30 24 lbs. (11 kg)
380–400–415 3.8–4.2–4.5 1 9.9–10.4–10.8 14 15 24 lbs. (11 kg)
208 4.5 3♦ 12.5 12 20 24 lbs. (11 kg)
240 4.5 3♦ 10.8 14 15 24 lbs. (11 kg)
380–400–415 3.8–4.2–4.5 3♦ 8.6–9.0–9.4 14 15 24 lbs. (11 kg)
415 4.5 3♦ 9.4 14 15 24 lbs. (11 kg)
480 4.5 3♦ 5.4 14 15 24 lbs. (11 kg)
FR-6 208 6.0 1 28.8 8 40 27 lbs. (12 kg)
240 6.0 1 25 8 40 27 lbs. (12 kg)
480 6.0 1 12.5 12 20 27 lbs. (12 kg)
220–230–240 5.0–5.5–6.0 1 23–24–25 8 40 27 lbs. (12 kg)
380–400–415 5.6–6.3–6.7 1 14.8–15.6–16.2 12 20 27 lbs. (12 kg)
208 6.0 3♦ 25 8 40 27 lbs. (12 kg)
240 6.0 3♦ 21.7 10 30 27 lbs. (12 kg)
380–400–415 5.6–6.3–6.7 3♦ 12.9–13.5–14 12 20 27 lbs. (12 kg)
415 6.0 3♦ 14 12 20 27 lbs. (12 kg)
480 6.0 3♦ 10.8 14 15 27 lbs. (12 kg)
480 6.0 3♦ 7.2 14 15 27 lbs. (12 kg)
FR-9 208 9.0 1 43.3 4 60 27 lbs. (12 kg)
240 9.0 1 37.5 6 50 27 lbs. (12 kg)
480 9.0 1 18.8 10 30 27 lbs. (12 kg)
220–230–240 7.6–8.3–9.0 1 34.4–35.9–37.5 6 50 27 lbs. (12 kg)
208 9.0 3♦ 37.5 6 50 27 lbs. (12 kg)
240 9.0 3♦ 32.5 8 40 27 lbs. (12 kg)
480 9.0 3♦ 16.2 12 20 27 lbs. (12 kg)
208 9.0 3♦ 25 8 40 27 lbs. (12 kg)
240 9.0 3♦ 21.7 10 30 27 lbs. (12 kg)
SPECIFICATIONS
Electrical Rating Chart—FR-X Models

Hatco 3CS-3 Specifications

General

Brand	Hatco
Model	3CS-3
Category	Heater
Language	English
