Hawk Gladiator AS2100 User Manual

6
Admittance Smart Switch Series
Manual
Rev 1.2, June 2008
7
Probe Length (mm, inch) Active + Guard + Ground
= 50mm, 2”
= 250mm, 9.8”
P30 (300mm,11.8”)
P50 (500mm, 19.7”)
= 750mm, 29.5”
P100 (1000mm, 39.4”)
250mm, 9.8”
250mm, 9.8”
250mm, 9.8”
+
+
+
Ground 100mm (3.9”)Guard 150mm (5.9”)Active (mm)
85mm (3.3”)
probe length
M20 cable gland
or 3/4” NPT adaptor
Window for
viewing status
LEDs
Mounting
thread
90mm (3.5”)
50mm (2”)
16mm (0.6”)
Ground 100mm (3.9”)
Guard 150mm (5.9”)Active (mm)
85mm (3.3”)
probe length
Window for
viewing status
LEDs
Optional Flange
90mm (3.5”)
50mm (2”)
2 x M20
cable glands
or 3/4” NPT adaptors
16mm (0.6”)
DIMENSIONS
REMOTE PROBE SMART PROBE

Hawk Gladiator AS2100 Specifications

General

Brand	Hawk
Model	Gladiator AS2100
Category	Switch
Language	English
