Hawk Gladiator AS2100 User Manual

8
Admittance Smart Switch Series
Manual
Rev 1.2, June 2008
9
DIMENSIONS
HIGH TEMPERATURE PROBES
HIGH TEMP PROBE (<250°C, <482°F) HIGH TEMP PROBE (450°C, 842°F)
Probe length
150mm
(5.9”)
Guard
Active
Element
Temperature extension
100mm
(3.9”)
Ground
Teflon
Teflon
Max 150ºC (302ºF)
Max 250ºC (482ºF)
SS 316
SS 316
SS 316
16mm (0.6”)
Mounting Thread
Ø90mm (3.5”) L100mm (4”)
Aluminium heat sink
Ceramic
Ceramic
Max 450ºC (842ºF)
SS 316
SS 316
36mm (1.4”)
329mm (13”)
Probe length
150mm
(5.9”)
Guard
Active
Element
100mm
(3.9”)
Ground
Mounting Thread
(1.5” NPT or BSP only)
90mm (3.5”)
90mm (3.5”)
(See page 5 for
temperature extension
options)
