33
+
>
>
+
+
+
>
>
>
>
>
>
Air Sensor
94ºF
Cell Temp Sensor
77ºF
Solar Sensor
Short circuit
Water Sensor
Open circuit
No function
No function
No function
No function
Move to previous/next menu item
Move to previous/next menu item
Move to previous/next menu item
Move to previous/next menu item
Available displays depend on configuration. If the sensor appears to operating properly,
then the temperature will be displayed. If this temperature is not correct then check the
placement of the sensor. If the problem is not placement related, then the sensor will, most
likely, require replacement. If the display is “Open Circuit” or “Short Circuit” then check the
wiring to the sensor and also make sure that the wires are secure in the terminal block in the
Aqua Logic main unit.
Main Software
Revision 2.40
Display Software
remote-08 r3.10
RF Base Software
r1.20 ID:1234
No function
No function
No function
Move to previous/next menu item
Move to previous/next menu item
Move to previous/next menu item
+
>
>
+
+
+
>
>
>
>
>
>
6B Spa Software
Remote A r1.00
No function
Move to previous/next menu item
Available displays depend on configuration. If you call the Goldline Technical Service
Department for assistance, they may ask for the software revisions of both the main unit and
each of the display/keypads or other devices that are attached to the system. Note that it is
possible that different display/keypads have different software revision levels. For this
reason, it is advisable to check this diagnostic menu item on every display.
