During this procedure the wireless remote “learns” and remembers the ID code for the
wireless base station connected to this particular Aqua Logic unit and will reject messages
with any other ID codes. If “Base NOT found” is displayed, then the Aqua Logic can not
communicate with the transmitter/receiver base station attached to the main unit. If “NOT
Successful” is displayed, then the base station did not receive a signal from the remote
control. This may be due to the distance between the Base Receiver and the remote device
being too great or may be due to interference caused by other RF equipment operating in the
neighborhood. Try changing the channel and then repeat the “Teach Wireless” command.
Wireless
Channel: 1
Reteach all
wireless units
Confirm Change:
+ to proceed
+
Push to confirm the channel change
Change the desired wireless channel (1 - 5)
>
>
Move to previous (Teach Wireless) menu
+
>
>
>
>
>
>
If channel is changed, move to confirmation menu
Move to previous/next menu item
If channel is not changed, move to previous/next menu item
This setting changes the channel to be used by the wireless base station and remote(s). If
the channel is changed and confirmed, all of the wireless remotes will have to be retaught.
This menu will only appear if a wireless base station is connected to the Aqua Logic.
Timers Menu
The Timers Menu allows you to set all timeclock and countdown timers which control the automatic
operation of your pool/spa system.
Each timeclock has a single on/off program per day. All of the timeclocks are setup (Configuration Menu)
either as “all days” or “weekends/weekdays”. If “weekends/weekdays” are selected, you will need to
program on times for both weekdays and weekends and off times for both weekdays and weekends, even
if you want them to be the same. All times are adjusted in 15 minute increments (9:00A, 9:15A, 9:30A,
etc.). If you program the on time equal to the off time (“10:00A to 10:00A”) the output will NEVER turn
on. If you want to disable a timeclock, you can set the on time equal to the off time and you will notice the
times disappear and the display simply shows “Off”. If, at a later time, you wish to re-activate the timeclock,
simply press either the “+” or “-” buttons to go back to a normal timeclock programming display.
The Countdown timer is programmed in increments of 5 minutes from “Manual On/Off” (0 minutes) to a
maximum of “21:00” (21 hours). When “Manual On/Off” is displayed, the countdown timer is disabled
and the output will be manually controlled. When a countdown timer is equal or greater than “0:05”,
pressing the appropriate output button will turn the output on and start the timer. Pressing the button again
will turn the output off or, when the programmed time has elapsed, the output will automatically turn off.
For one speed pumps, this is the first filter timeclock and will determine the normal hours of
filtration for the pool. For pool/spa combination systems with spillover enabled, the valves
will automatically switch to spillover mode at the start of the filtration period. For all other
systems, the valves will switch to the pool-only position. Refer to the text above for general
notes regarding timeclock programming.
Set Day and Time
Wednesday 10:37P
+
>
>
Adjust time setting
Move between start and stop times & to previous/next menu item
Filter T1-all
8:30A to 4:00P
+
>
>
Adjust time s
Filter T1-wkend
8:30A to 4:00P
Filter T1-wkday
8:30A to 4:00P
+
+
>
>
>
>
Adjust time setting
Adjust time setting
Move between start and stop times & to previous/next menu item
Move between start and stop times & to previous/next menu item
or
To Next Page
