USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

This pump can communicate with and be controlled by Hayward pool controls such as OmniLogic™, ProLogic

, ECommand

4, OnCommand

, OmniHub, S3

Omni, and OmniPL. Minimum software revision requirements: OmniLogic R1.0.0, ProLogic 3.00, OnCommand 1.00, E-Command 2.65, E-Command 4 2.80,

AquaLogic 2.65, and AquaPlus 2.65. To determine Hayward control software revision, consult the pool control installation manual or visit our website at: www.

haywardpool.com. Connection wire must be rated for a minimum of 300V, and may be up to 500 feet in length. Use removable 4-position terminal block con-

nector for wiring connection to motor drive PCB, taking care to note the wire colors and corresponding numbers next to the connectors. Terminal block must

be installed with screws facing up to ensure proper connection.

ATTENTION – THIS PUMP CAN ALSO BE SET SO THAT IT WILL CONTINUE RUNNING IN THE EVENT OF COMMUNICATION LOSS. When inputs are activated

via wire jumpers, the pump will respond to a communication loss (after a 4 minute delay) as follows:

1. No inputs connected: pump remains stopped

2. INP1 connected: pump runs 3450 rpm for 8 minutes, then 1725 rpm

3. INP2 connected: pump runs 3450 rpm for 8 minutes, then 2600 rpm

4. INP3 connected: pump runs 3450 rpm

See page 14 for details regarding input connections (relays would not be used when connecting inputs to set comm loss behavior; use short jumpers in

this case). Note: Prior to drive comm revision 10.10, pump response was as follows: no inputs connected – pump runs 3450 rpm for 8 minutes then 1725

rpm; INP1 connected – pump runs 3450 rpm for 8 minutes then 2600 rpm; INP2 connected – pump runs 3450; INP3 connected – pump remains stopped.

Jumpers, if used to set desired behavior in the event of communication loss, need to be installed at initial pump installation.

When communicating with the Omni family of controls, the HUA (Hayward Unique Address) is used for communication. For all other Hayward controls, the pump

address must be set using the DIP switches on the drive PCB. To determine which address should be used, consult the appropriate Hayward pool control instal-

lation manual, or visit our website at www.haywardpool.com. Pump addresses are set according to the table below.

DIS SWITCH STATUS

PUMP ADDRESS #1 #2 #3 #4 #5

Pool Filter OFF OFF OFF OFF OFF

AUX 1 / Spa Filter OFF ON OFF OFF OFF

AUX 2 OFF OFF ON OFF OFF

AUX 3 OFF ON ON OFF OFF

AUX 4 OFF OFF OFF ON OFF

AUX 5 OFF ON OFF ON OFF

AUX 6 OFF OFF ON ON OFF

AUX 7 OFF ON ON ON OFF

AUX 8 OFF OFF OFF OFF ON
