Hayward W3SP3202VSP User Manual

USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
20
5.
6.
7.
8.
NOTE: When start/stop times are set to be the same, the timer is deactivated. Each timer can be set to run on specific days of the week. Options are to run 7
days per week, 5 days per week (Monday thru Friday), or on a single day (Monday thru Sunday). Each timer is set up in this same manner. If the timers are set
up such that their run times overlap, the timers will run in priority from Timer 1 to Timer 8. In other words, if Timer 1 is set to run from 8:00 am to 12:00 pm,
and Timer 2 is set to run from 10:00 am to 2:00 pm, the pump will run Timer 1 from 8:00 am to 12:00 pm, and will then switch to run Timer 2 until 2:00 pm.
Default setting for Timer 1 is to start at 12:00 am, and end at 11:45 pm. When Remote Control Mode is set to Relay Control, the speed for Timer 1 may be set
to 0 rpm to allow the pump to be stopped without having to remove power.
Preset Speed Setup Menu
1.
2.
3.
4.
5.
6.
NOTE: Preset Speed settings can also be quickly updated without entering the Speeds Menu using the + and - arrow buttons to change the speed and then
pressing the > button to save the new speed setting.
Use > button to enter Speeds Menu.
Screen Buttons Used Comments
Speeds Menu
Press > to enter
Press +/- to change
or > view next item
< >
Use to change displayed speed.
Move to next menu item.
Speed 1
1150rpm
Press + to change
or > next speed
+ -
< >
Use to rename speed.
Move to next menu item.
Use to set motor speed for displayed speed.
Move to next menu item.
S1: Speed 1
+/- rename; > speed
Speed 1 1725rpm
+/- adjust
+ -
< >
+ -
< >
Use + button to rename timer.
Use > button to set motor speed for timer.
Use to set speed for timer.
Use > button to set start/stop time.
Screen Buttons Used Comments
T1: Timer 1
+/- rename; speed >
Timer 1 1725rpm
+/- adjust; times >
+ -
< >
+ -
< >
Use to set start/stop time for timer.
Use > to choose days of operation for timer.
Use to choose days of operation for timer.
Move to next menu item.
Timer 1 1725rpm
8:00a to 6:00p
Choose Days
7D 7 days a week
+ -
< >
+ -
< >
