CROSS SECTION OF HDG F20-50
1Central module
2 EM4 extension module (optional)
3Side panels
4 Burner nozzle
5Ash compartment
6 Combustion chamber
7 Nozzle brick
8Back panels
9 Tubular heat exchanger
10 Cleaning turbulators
11 Flue gas flap
12 Cleaning shaft lid
Figure 3/2 - Cross section of HDG F20-50
