Heath Zenith 5412 - Wiring the Light Control; Mounting the Light Control

3
204026-01
1. Removetheexistinglightxture.
2. Installthemountingstrapasshownusingtwoscrews
thattyourjunctionbox.
3. Theplastichangercanbeusedtoholdthexture
whilewiring.Thesmallendoftheplastichanger
canbethreadedthroughtheholeinthecenterof
thecoverplate.Thesmallendthengoesintoone
oftheslotsonthemountingstrap.
4. Route the light control’s wires through the large
gasketholes.
5. Twistthejunctionboxwiresandxturewirestogether
asshown.Securewithwireconnectors.
White to
White
Black to
Black
Junction box ground wire to
green ground screw on fixture.
Gasket
Mounting
Strap
Mounting
Bolt
Rubber
Plug
Mount the Light Control
1. Alignthelightcontrolcoverplateandcoverplate
gasket.Securewiththemountingbolt.
2. Alignthethreeslotsinthedecorativeshellwiththe
bulbholderpins.Pushtheshellinandthentwist
clockwisetolock.Repeatforothershell.
LockNut
Toavoidwaterdamageandelectricalshock,
keepbulbholders30°belowhorizontal.
5. Adjustthebulbholdersbylooseningthelocknuts
butdonotrotatethebulbholdersmorethan180°
fromthefactorysetting.
6. Installoodlamps.Whenscrewingintheoodlamps,
do not overtighten. NOTE: Compact uorescent
lamps(CFL)mustbeagencylistedandratedfor
outdooruse.
Keepbulbsatleast
1"(25mm)fromthe
sensor.Donotallow
the bulbs to block
thelens.
3. Pushtherubberplugrmlyintoplace.
4. Ifawetlocationjunctionboxwasnotused,caulk
the wall plate mounting surface with silicone
weathersealant.
ShellSlot
Wire the Light Control
WARNING: Turn power off at circuit breaker
or fuse.
Lens
