Heath Zenith 5412 - Specifications; Troubleshooting Guide

5
204026-01
SYMPTOM POSSIBLE CAUSE SOLUTION
Lights will not come
on.
1. Lightswitchisturnedoff.
2. Floodlampislooseorburnedout.
3. Fuseisblownorcircuitbreakeristurnedoff.
4. Daylightturn-offisineffect.
5. Incorrectcircuitwiring,ifthisisanewinstallation.
6. Lightcontrolaimedinwrongdirection.
1. Turnlightswitchon.
2. Checkoodlampandreplaceifburnedout.
3. Replacefuseorturncircuitbreakeron.
4. Recheckafterdark.
5. Verifywiringiscorrect.
6. Re-aimlightcontroltocoverdesiredarea.
Lightscomeoninday-
light.
1. Light control may be installedin a relatively dark
location.
2. LightcontrolisinTEST.
1. Thextureisoperatingnormallyunderthesecondi-
tions.
2. Setcontrolswitchto1,5,or10minutes.
Lights come on for no
apparentreason.
1. Lightcontrolmaybesensingsmallanimalsorauto-
mobiletrafc.
2. Rangeissettoohigh.
1. Re-aimlightcontrol.
2. Reducerange.
Lightsturnofftoolatein
Dusk-to-Dawnsetting.
Lightcontrolmaybeinstalledinarelativelydarkloca-
tion.
Relocatelightcontrol,oruse3houror6hoursetting.
Lightsstayoncontinu-
ously.
1. Aoodlampispositionedtooclosetothelightcontrol
orpointedatnearbyobjectsthatcauseheattotrigger
thelightcontrol.
2. Thelightcontrolmaybepickingupaheatsource
likeanairvent,dryervent,orbrightlypainted,heat-
reectivesurface.
3. Lightcontrolisinmanualmode.
1. Repositiontheoodlampawayfromthelightcontrol
ornearbyobjects.
2. Reducerange.
3. SwitchlightcontroltoAUTO.
Lightsashonandoff. 1. Heatorlightfromtheoodlampsmaybeturningthe
lightcontrolonandoff.
2. Heatbeingreectedfromotherobjectsmaybeturn-
ingthelightcontrolonandoff.
3. LightcontrolisintheTESTmodeandwarmingup.
4. Lightmaybeleakingthroughtheoodlampreec-
tors.
1. Repositiontheoodlampawayfromthelightcon-
trol.
2. Repositionlightcontrol.
3. Flashingisnormalundertheseconditions.
4. ReplacetheoodlampswithnewhighqualityPAR
38lamps.(Makesurethemetallampprotectorsare
installed).
Lightsashonce,then
stay off in manual
mode.
Lightcontrolisdetectingitsownlights. Reposition ood lampsto keep area belowthe light
controlrelativelydark.
SPECIFICATIONS
Range............Upto70ft.(21m)[varieswith
surroundingtemperature].
SensingAngle......Upto180°
ElectricalLoad......Upto300WattMaximumTung-
sten[Upto150Wattmaximum
eachbulbholder.]
 Up to 60Watt Maximumself-
ballasted CFL [Up to 30Watt
maximumeachbulbholder.]
TROUBLESHOOTING GUIDE
PowerRequirements. 120VAC,60Hz
OperatingModes....TEST, AUTO, and MANUAL
MODE
TimeDelay ........1,5,10minutes
Range............Adjustable
HeathCoLLCreservestherighttodiscontinueprod-
uctsandtochangespecicationsatanytimewithout
incurringanyobligationtoincorporatenewfeatures
inproductspreviouslysold.
