4. Adjust volume control (Available on se-
lected chimes). Unplug chime and adjust
volume control to desired volume (see Figure
2).Plugchimebackintowalloutlet.
5. Mount push button. Use either screwsor
double sided tape to mount push button.
• Screw Mounting: To mount with screws,
remove back of case by pushing in tab on
bottomwithasmallscrewdriver(seeFigure
1). Note:Removematerialinscrewholes
(ifneeded)before mountingwithscrews.
Attachbackofcasetodoorjamborwall(see
Figure 3). Snap front of push button on.
• Tape Mounting:Whenattachingpushbut-
ton using double sided tape, make sure the
surfaceofthedoorjamborwallisclean.
Chime Volume Control
(Selected Chimes)
Figure 3
TOP
Figure 2
Jumper Access Door (See
Tune or Code Section)
C A U T I O N :
D I S C O N N E C T
P O W E R B E F O R E
O P E N I N G
VO LUME
