08/04 30803 Rev X 27
CALIBER DIRECT VENT INSTALLATION INSTRUCTIONS
Figure 59 - Placing the Vermiculite, Lava Rock, Rock Wool and Fire Glow.
Figure 63 - Placing the Fire Glow
Figure 60 - Placing the Lava Rock
WARNING - RISK OF CARBON MONOXIDE!
Never operate this appliance with the glass removed or not sealed.
Installation is now complete.
Figure 62 - Placing the Rock Wool
Figure 61 - Placing the Vermiculite
