CALIBER DIRECT VENT INSTALLATION INSTRUCTIONS
Components Description
DRC-RADIUS Cap Shield
COOL-ADDM Cap Shield - pack of six
DVP-TV Vertical Termination Cap
DVP45 45-deg Elbow
DVP90 90-deg Elbow (for Heatilator appliances only)
DVP90ST 90-deg Starter Elbow (should be the first 90-deg elbow used)
RF6M Roof Flashing (vertical termination for 0/12 to 6/12 pitch) - pack of four
RF12M Steep Pitch Roof Flashing (for 7/12 to 12/12 pitch) - pack of six
DVP4 4 in. length Vent Pipe
DVP6 6 in. length Vent Pipe
DVP12 12 in. length Vent Pipe
DVP24 24 in. length Vent Pipe
DVP36 36 in. length Vent Pipe
DVP48 48 in. length Vent Pipe
DVP6A 3-6 in. Slip Section Vent Pipe (to be used with another piece of pipe)
DVP12A 3-12 in. Slip Section Vent Pipe (to be used with another piece of pipe)
DV P12MI 12 in. Vent P ipe - non-unitized (can be cut to length)
DVP24MI 24 in. Vent Pipe - non-unitized (can be cut to length)
DVP-HVS Vent Support
DVP-WS Wall Shield to ensure horizontal clearances
DVP-FS Firestop Spacer
DVP-TRAP1 Horizontal Termination Cap with 1-3/4 in. telescoping flue and wall shield with heat shield
DVP-TRAP2 Horizontal Termination Cap with 4 in. telescoping flue and wall shield with heat shield
DVP-TB1 Basement Horizontal Termination Cap
DVP-TRAPK1 Top Vent Horizontal Kit with DVP-TRAP1 Termination Cap, wall shield with heat shield, and starter elbow
DVP-TRAPK2 Top Vent Horizontal Kit with DVP-TRAP2 Termination Cap, wall shield with heat shield, and starter elbow
DVP-HSM Extended Heat Shield
BEK Brick Extension Kit
DVP-AS Attic Insulation Shield
Catalog # Description
GCDC60 41 in. width, 36 in. opening, Standing Pilot - Natural Gas Application
GCDC80 47 in. width, 42 in. opening, Standing Pilot - Natural Gas Application
The following suffixes are defined as follows:
No suffix Natural Gas, Standing Pilot
L Propane Gas, Standing Pilot
I Natural Gas, Intermittent Pilot
IL Propane Gas, Intermittent Pilot
R Refractory
F Fan
Examples: GCDC60IL is a Propane Gas, Intermittent Pilot Appliance
GCDC60IF is a Natural Gas, Intermittent Pilot Appliance
CALIBER NOMENCLATURE
