10 Programming: Q Parameters
266
Group name, ID No. Number Index System data
Data from the tool table, 50 1 Tool no. Tool length
2 Tool no. Tool radius
3 Tool no. Tool radius R2
4 Tool no. Oversize for tool length DL
5 Tool no. Oversize for tool radius DR
6 Tool no. Oversize for tool radius DR2
7 Tool no. Tool inhibited (0 or 1)
8 Tool no. Number of replacement tool
9 Tool no. Maximum tool age TIME1
10 Tool no. Maximum tool age TIME2
11 Tool no. Current tool age CUR. TIME
12 Tool no. PLC status
13 Tool no. Maximum tooth length LCUTS
14 Tool no. Maximum plunge angle ANGLE
15 Tool no. TT: Number of teeth CUT
16 Tool no. TT: Wear tolerance for length LTOL
17 Tool no. TT: Wear tolerance for radius RTOL
18 Tool no. TT: Rotational direction DIRECT (0=positive/-1=negative)
19 Tool no. TT: Offset for radius R-OFFS
20 Tool no. TT: Offset for length L-OFFS
21 Tool no. TT: Breakage tolerance in length LBREAK
22 Tool no. TT: Breakage tolerance in radius RBREAK
No index: Data of the currently active tool
Pocket table data, 51 1 Pocket number Tool number
2 Pocket number Special tool: 0=no, 1=yes
3 Pocket number Fixed pocket: 0=no, 1=yes
4 Pocket number Locket pocket: 0=no, 1=yes
5 Pocket number PLC status
Pocket number of a tool in
the tool pocket table, 52 1 Tool no. Pocket number
Immediately after TOOL CALL
programmed position, 70 1 – Position valid / invalid (1/0)
2 1 X axis
2 2 Y axis
2 3 Z axis
3 – Programmed feed rate (-1: no feed rate programmed)
Active tool compensation, 200 1 – Tool radius (including delta values)
2 – Tool length (including delta values)
10.8 Additional Functions
