HEIDENHAIN TNC 426 B, TNC 430 267
Group name, ID No. Number Index System data
Active transformations, 210 1 – Basic rotation in MANUAL OPERATION mode
2 – Programmed rotation with Cycle 10
3 – Active mirror axis
0: mirroring not active
+1: X axis mirrored
+2: Y axis mirrored
+4: Z axis mirrored
+64: U axis mirrored
+128: V axis mirrored
+256: W axis mirrored
Combinations = sum of individual axes
4 1 Active scaling factor in X axis
4 2 Active scaling factor in Y axis
4 3 Active scaling factor in Z axis
4 7 Active scaling factor in U axis
4 8 Active scaling factor in V axis
4 9 Active scaling factor in W axis
5 1 3D ROT A axis
5 2 3D ROT B axis
5 3 3D ROT C axis
6 – Tilted working plane active / inactive (-1/0)
Active datum shift, 220 2 1 to 9 Index 1=X axis 2=Y axis 3=Z axis
Index 4=A axis 5=B axis 6=C axis
Index 7=U axis 8=V axis 9=W axis
Traverse range, 230 2 1 to 9 Negative software limit switch
Axes 1 to 9
3 1 to 9 Positive software limit switch
Axes 1 to 9
Nominal position in the REF
system, 240 1 1 to 9 Index 1=X axis 2=Y axis 3=Z axis
Index 4=A axis 5=B axis 6=C axis
Index 7=U axis 8=V axis 9=W axis
Nominal positions in the
input system, 270 1 1 to 9 Index 1=X axis 2=Y axis 3=Z axis
Index 4=A axis 5=B axis 6=C axis
Index 7=U axis 8=V axis 9=W axis
Triggering touch probe, 350 10 – Touch probe axis
11 – Effective ball radius
12 – Effective length
13 – Radius setting ring
14 1 Center misalignment in main axis
2 Center misalignment in secondary axis
15 – Direction of center misalignment compared with 0°
position
