10 Programming: Q Parameters
268
10.8 Additional Functions
Group name, ID No. Number Index System data
Tool touch probe 120 20 1 Center point X-axis (REF system)
2 Center point Y-axis (REF system)
3 Center point Z-axis (REF system)
21 – Probe contact radius
Measuring touch probe, 350 30 – Calibrated stylus length
31 – Stylus radius 1
32 – Stylus radius 2
33 – Setting ring diameter
34 1 Center misalignment in main axis
2 Center misalignment in secondary axis
35 1 Compensation factor for 1st axis
2 Compensation factor for 2nd axis
3 Compensation factor for 3rd axis
36 1 Power ratio for 1st axis
2 Power ratio for 2nd axis
3 Power ratio for 3rd axis
Data from the active
datum table, 500 (datum number) 1 to 9 Index 1=X axis 2=Y axis 3=Z axis
Index 4=A axis 5=B axis 6=C axis
Index 7=U axis 8=V axis 9=W axis
Datum table selected, 505 1 – Acknowledgement value = 0: No datum table active
Acknowledgement value = 1: Datum table active
Data from the active
pallet table, 510 1 – Active line
2 – Palette number from PAL/PGM field
Machine parameter
exists, 1010 MP number MP index Acknowledgement value = 0: MP does not exist
Acknowledgement value = 1: MP exists
Example: Assign the value of the active scaling factor for the Z axis
to Q25.
55 FN18: SYSREAD Q25 = ID210 NR4 IDX3
MKAP10.PM6 30.06.2006, 07:04268
