10 Programming: Q Parameters
274
Overlap factor: Q112
The overlap factor for pocket milling (MP7430) is assigned to Q112.
Unit of measurement for dimensions in the program: Q113
The value of parameter Q113 specifies whether the highest-level
NC program (for nesting with PGM CALL) is programmed in
millimeters or inches.
Dimensions of the main program Parameter value
Metric system (mm) Q113 = 0
Inch system (inches) Q113 = 1
Tool length: Q114
The current value for the tool length is assigned to Q114.
Coordinates after probing during program run
The parameters Q115 to Q119 contain the coordinates of the
spindle position at the moment of contact during programmed
measurement with the 3-D touch probe.
The length and radius of the probe tip are not compensated in
these coordinates.
Coordinate axis Parameter
X axis Q115
Y axis Q116
Z axis Q117
IVth axis (dependent on MP100) Q118
Vth axis (dependent on MP100) Q119
Deviation between actual value and nominal value during
automatic tool measurement with the TT 120
Actual-nominal deviation Parameter
Tool length Q115
Tool radius Q116
Tilting the working plane with mathematical angles: Rotary axis
coordinates calculated by the TNC
Coordinates Parameter
A axis Q120
B axis Q121
C axis Q122
10.10 Preassigned Q Parameters
