HEIDENHAIN TNC 426 B

HEIDENHAIN TNC 426 B, TNC 430 275
Results of measurements with touch probe cycles
(see also Touch Probe Cycles User's Manual)
Measured actual values Parameter
Center in reference axis Q151
Center in minor axis Q152
Diameter Q153
Length of pocket Q154
Width of pocket Q155
Length in the axis selected in the cycle Q156
Position of the center line Q157
Angle of the A axis Q158
Angle of the B axis Q159
Coordinate of the axis selected in the cycle Q160
Measured deviation Parameter
Center in reference axis Q161
Center in minor axis Q162
Diameter Q163
Length of pocket Q164
Width of pocket Q165
Measured length Q166
Position of the center line Q167
Workpiece status Parameter
Good Q180
Re-work Q181
Scrap Q182
10.10 Preassigned Q Parameters
