13 Tables and Overviews
320
13.1 General User Parameters
3-D touch probes and digitizing
Select touch probe
(only with option for digitizing with measuring touch probe)
MP6200
Triggering touch probe: 0
Measuring touch probe: 1
Select signal transmission
MP6010
Touch probe with cable transmission: 0
Touch probe with infrared transmission: 1
Probing feed rate for triggering touch probes
MP6120
1 to 3000 [mm/min]
Maximum traverse to first probe point
MP6130
0.001 to 99 999.9999 [mm]
Safety clearance to probing point during automatic measurement
MP6140
0.001 to 99 999.9999 [mm]
Rapid traverse for triggering touch probes
MP6150
1 to 300 000 [mm/min]
Measure center misalignment of the stylus when calibrating a triggering touch probe
MP6160
No 180° rotation of the 3-D touch probe during calibration: 0
M function for 180° rotation of the 3-D touch probe during calibration:
1 to 88
Multiple measurement for programmable probe function
MP6170
1 to 3
Confidence range for multiple measurement
MP6171
0.001 to 0.999 [mm]
Infeed of the stylus when digitizing with the measuring touch probe
MP6310
0.1 to 2.0000 [mm] (recommended input value: 1 mm)
Measure center misalignment of the stylus when calibrating a measuring touch probe
MP6321
Measure center misalignment: 0
Do not measure center misalignment: 1
