HEIDENHAIN TNC 426 B

HEIDENHAIN TNC 426 B, TNC 430 321
13.1 General User Parameters
Assign touch probe axis to machine axis for a measuring touch probe
MP6322.0
Machine X axis parallel to touch probe axis X: 0, Y: 1, Z: 2
MP6322.1
Machine Y axis parallel to touch probe axis X: 0, Y: 1, Z: 2
MP6322.2
Machine Z axis parallel to touch probe axis X: 0, Y: 1, Z: 2
Maximum stylus deflection of the measuring touch probe
MP6330
0.1 to 4.0000 [mm]
Feed rate for positioning measuring touch probes at MIN point and approaching the contour
MP6350
1 to 3000 [mm/min]
Probe feed rate for measuring touch probes
MP6360
1 to 3000 [mm/min]
Rapid traverse for measuring touch probes in the probe cycle
MP6361
10 to 3 000 [mm/min]
Feed rate reduction when the stylus of a measuring touch probe is deflected to the side
The TNC decreases the feed rate according to a
preset characteristic curve. The minimum input
value is 10% of the programmed digitizing feed
rate.
MP6362
Feed rate reduction not active: 0
Feed rate reduction active: 1
Radial acceleration during digitizing with the measuring touch probe
MP6370 enables you to limit the feed rate of the
TNC for circular movements during digitizing.
Circular movements are caused, for example, by
sharp changes of direction.
As long as the programmed digitizing feed rate is
less than the feed rate calculated with MP6370,
the TNC will move at the programmed feed rate.
Determine the appropriate value for your
requirements by trial and error.
MP6370
0.001 to 5.000 [m/s
2
] (recommended input value: 0.1)
Ensure that the touch probe axes are
correctly assigned to the machine axes.
Wrong assignment could lead to a
stylus break.
