HEIDENHAIN TNC 426 B, TNC 430 323
13.1 General User Parameters
Measuring rotating tools: Permissible rotational speed at the circumference of the milling tool
Required for calculating rpm and probe feed rate
MP6570
1.000 to 120.000 [m/min]
Coordinates of the TT 120 stylus center relative to the machine datum
MP6580.0 (traverse range 1)
X axis
MP6580.1 (traverse range 1)
Y axis
MP6580.2 (traverse range 1)
Z-axis
MP6581.0 (traverse range 2)
X-axis
MP6581.1 (traverse range 2)
Y-axis
MP6581.2 (traverse range 2)
Z-axis
MP6582.0 (traverse range 3)
X-axis
MP6582.1 (traverse range 3)
Y-axis
MP6582.2 (traverse range 3)
Z-axis
TNC displays, TNC editor
Programming station
MP7210
TNC with machine: 0
TNC as programming station with active PLC: 1
TNC as programming station with inactive PLC: 2
Acknowledgment of POWER INTERRUPTED after switch-on
MP7212
Acknowledge with key: 0
Acknowledge automatically: 1
ISO programming: Block number increment
MP7220
0 to 150
