HEIDENHAIN TNC 426 B, TNC 430 327
Configure pocket tables (to omit from table enter 0); Column number in the tool table for
MP7267.0
Tool number — T: 0 to 5
MP7267.1
Special tool — ST: 0 to 5
MP7267.2
Fixed pocket — F: 0 to 5
MP7267.3
Pocket locked — L: 0 to 5
MP7267.4
PLC status — PLC: 0 to 5
Manual Operation mode: Display of feed rate
MP7270
Display feed rate F only if an axis direction button is pressed: 0
Display feed rate F even if no axis direction button is pressed
(feed rate defined using F soft key or feed rate of the “slowest” axis): 1
Decimal character
MP7280
The decimal character is a comma: 0
The decimal character is a point: 1
Position display in the tool axis
MP7285
Display is referenced to the tool datum: 0
Display in the tool axis is referenced to the tool face: 1
Display step for the X axis
MP7290.0
0.1 mm: 0
0.05 mm: 1 0.001 mm: 4
0.01 mm: 2 0.0005 mm: 5
0.005 mm: 3 0.0001 mm: 6
Display step for the Y axis
MP7290.1
For input values, see MP7290.0
Display step for the Z axis
MP7290.2
For input values, see MP7290.0
Display step for the IVth axis
MP7290.3
For input values, see MP7290.0
Display step for the V axis
MP7290.4
For input values, see MP7290.0
13.1 General User Parameters
