HEIDENHAIN TNC 426 B, TNC 430 329
13.1 General User Parameters
Graphic display mode
MP7310
Projection in three planes according to ISO 6433, projection
method 1: +0
Projection in three planes according to ISO 6433, projection
method 2: +1
Do not rotate coordinate system for graphic display: +0
Rotate coordinate system for graphic display by 90°: +2
Display new BLK FORM in Cycle 7 DATUM SHIFT referenced to the
previous datum +0
Display new BLK FORM in Cycle 7 DATUM SHIFT referenced to the
new datum:+4
Do not show cursor position during projection in three planes: +0
Show cursor position during projection in three planes: +8
Graphic simulation without programmed tool axis: Tool radius
MP7315
0 to 99 999.9999 [mm]
Graphic simulation without programmed tool axis: Penetration depth
MP7316
0 to 99 999.9999 [mm]
Graphic simulation without programmed tool axis: M function for start
MP7317.0
0 to 88 (0: Function inactive)
Graphic simulation without programmed tool axis: M function for end
MP7317.1
0 to 88 (0: Function inactive)
Screen saver
Enter the time after which the TNC should start
the screen saver
MP7392
0 to 99 [min] (0: Function inactive)
Machining and program run
Cycle 17: Oriented spindle stop at beginning of cycle
MP7160
Oriented spindle stop: 0
No oriented spindle stop: 1
Effect of Cycle 11 SCALING FACTOR
MP7410
SCALING FACTOR effective in 3 axes: 0
SCALING FACTOR effective in the working plane only: 1
Tool data in programmable probe cycle TOUCH–PROBE 0
MP7411
Overwrite current tool data by the calibrated data from the 3-D touch
probe system: 0
Current tool data are retained: 1
