To
select drives, directories and files:
Calling the file manager
<
With the arrow keys or the soft keys, you can move the highlight to
the desired position on the screen:
Move the highlight from the left to the right
window, and vice versa.
Move the highlight up and down within a
window
Move the highlight one page up or
down within a window
1st step: select drive:
Move the highlight to the desired drive in the left window:
<
or Select drive: Press the SELECT soft key
or ENT
2nd step: select directory:
Move the highlight to the desired directory in the left window —
the right window automatically shows all files stored in the
highlighted directory.
4.4 File Management with Additional Functions
