72
5 Programming: Tools
5.2 Tool Data
Tool table: Additional tool data for automatic speed/feed rate
calculations.
Abbr. Input
TYPE Tool type (MILL=for milling, DRILL=for drilling or
boring, TAP=for tapping): Press the SELECT TYPE soft
key (3rd soft-key row): The TNC superimposes a
window where you can select the type of tool you want.
TMAT Tool material: Press the SELECT MATERIAL soft key
(3rd soft-key row): The TNC superimposes a window
where you can select the type of material you want.
CDT Cutting data table: Press the SELECT CDT soft key
(3rd soft-key row): The TNC superimposes a window
where you can select a cutting data table.
Dialog
Tool type ?
Tool material ?
Name of cutting data table ?
Abbr. Input
CUT. Number of teeth (20 teeth maximum)
LTOL Permissible deviation from tool length L for wear
detection. If the entered value is exceeded, the TNC
locks the tool (status L).
Input range: 0 to 0.9999 mm
RTOL Permissible deviation from tool radius R for wear
detection. If the entered value is exceeded, the TNC
locks the tool (status L).
Input range: 0 to 0.9999 mm
DIRECT. Cutting direction of the tool for measuring the tool
during rotation
TT:R-OFFS Tool length measurement: tool offset between stylus
center and tool center. Preset value: Tool radius R (NO
ENT means R)
TT:L-OFFS Tool radius measurement: tool offset in addition to
MP6530 (see „13.1 General User Parameters“) bet-
ween upper surface of stylus and lower surface of tool.
Preset value: 0
LBREAK Permissible deviation from tool length L for break
detection. If the entered value is exceeded, the TNC
locks the tool (status L).
Input range: 0 to 0.9999 mm
RBREAK Permissible deviation from tool radius R for break
detection. If the entered value is exceeded, the TNC
locks the tool (status L).
Input range: 0 to 0.9999 mm
Dialog
Number of teeth ?
Wear tolerance: length ?
Wear tolerance: radius ?
Cutting direction (M3 = –) ?
Tool offset: radius ?
Tool offset: length ?
Breakage tolerance: length ?
Breakage tolerance: radius ?
Tool table: Tool data required for automatic tool measurement
For a description of the cycles governing automatic tool
measurement, see the new Touch Probe Cycles Manual,
Chapter 4.
