Heinzmann PANDAROS DC 6-06 User Manual

7 Technical data
42 Positioner DC 6-06
7.3.1 Analogue setpoint, stop signal digital and/or analogue, actuator with disc
rotor motor
234567891011121314151617
T
18
C
B
D
A
E
M
DC ... 6-06
StG 6 .. 40 - 01
Actuator
Fuse
12 A
Control
on
Control unit
Common alarm
Stop digital
22 23 24 25
CU-01

k
max.
min.

Setpoint potentiometer
cw
out
ccw
or setpoint
with voltage signal
or setpoint
with current signal
0 V
4-20 mA
0 V
0-5 V
1LH 19 20 21
StG actual position
with analogue signal
or PWM signal
0 V
analog/PWM
Stop analogue
Error reset
Supply voltage
12 V DC or 24 V DC
+
-
Fig. 2 Terminal connection diagram 1
– Analogue setpoint, stop signal digital and/or analogue, actuator with disc rotor motor

Heinzmann PANDAROS DC 6-06 Specifications
