11 Parameter description
Positioner DC 6-06 85
11.4 List 3: Functions
Name Meaning
4330 ChanTyp_FuelSetp
Level: 6
Range: 0..10
Page(s): 17, 19, 30, 32
Configuratio
n of the input channel type of the setpoint
generator
0 = analogue
1 = PWM (RESET)
4331 SubstOrLastFuelSetp
Level: 4
Range: 0/1
Page(s): 25
Selection of the equivalent
value for the setpoint
generator in case of error (0 = last valid value,
1 = equivalent value 331 FuelSetpSubst)
(RESET)
4332 HoldOrResetFuelSetp
Level: 4
Range: 0/1
Page(s): 25
Selects wh
ether the error at the setpoint generator is
reset or held when the signal returns
(0 = error cleared, 1 = error retained)
(RESET)
4335 ActPosOutPWMOrAnalog
Level: 4
Range: 0/1
Page(s): 36
Configuratio
n of the output channel type for the display
of the current actuator position
0 = analogue
1 = PWM (RESET)
4340 AnaStopRequestUsed
Level: 6
Range: 0/1
Page(s): 24, 30, 32
Activates the
analogue stop request
(RESET)
4341 AnaStopSubstOrLast
Level: 6
Range: 0/1
Page(s): 26
Selects the eq
uivalent value for the analogue stop
request in case of error (0 = last valid value,
1 = equivalent value 1000 AnaStopSensorSubst)
(RESET)
4342 AnaStopHoldOrReset
Level: 6
Range: 0/1
Page(s): 26
Selects wh
ether the error at the analogue stop request is
reset or held when the signal returns
(0 = error cleared, 1 = error retained)
(RESET)
4721 FuelToActPosCurveOn
Level: 4
Range: 0/1
Page(s): 20
Activates the
filling-dependent actuator nominal
position (curve)
(RESET)
