11 Parameter description
78 Positioner DC 6-06
11.3 List 2: Measured values
Name Meaning
2300 ActPos
Level: 1
Range: 0..100 %
Page(s): 50, 52, 54
Current actuator position
2330 ActPosSetpo
int
Level: 1
Range: 0..100 %
Page(s): 20, 52
Control path
setpoint for the actuator
2350 FuelSetpoint
Level: 1
Range: 0..100 %
Page(s): 20, 22, 32, 52
Setpoint
2809 AnaStopRequest
Level: 1
Range: 0/1
Page(s): 23, 26
State of the stop request vi
a analogue input
2810 SwitchStopRequest
Level: 1
Range: 0/1
Page(s): 23
State of the stop request via digital input
2828 SwitchEr
rorReset
Level: 1
Range: 0/1
Page(s): 31, 58
State of the switch function “Error reset
”
2845 SwitchAutoAdjust
Level: 1
Range: 0/1
Page(s): 31, 50
State of the switch function “Autom
atic actuator
adjustment”
2900 AnaStopSensor
Level: 1
Range: 0..100 %
Page(s): 24, 26, 32
Current measured value of
the analogue stop input
3000 ConfigurationError
Level: 1
Range: 0..65535
Page(s): 62, 64
Display
s configuration errors
3005 ErrAnaStopRequest
Level: 1
Range: 0/1
Page(s): 26, 64
Error displa
y of the analogue stop input
